Kenwood NX-3720E VHF NEXEDGE/DMR/Analogue Mobile Radio
Kenwood NX-3720E VHF NEXEDGE/DMR/Analogue Mobile Radio
The Kenwood NX-3720E VHF NEXEDGE/DMR/Analogue Mobile Radio from Radio-Shop.uk supports both NXDN and DMR digital protocols as well as mixed digital & FM analogue operation, enabling it to serve with distinction in a wide range of enterprise and operation-critical applications.
Providing greater freedom of installation, the radio’s front panel can be used as a remote control head (this requires an optional upgrade, to be available in future). Additionally, for expansion capability a software license certification system facilitates extensive customisation.
Please click here to see the compatible accessories for this radio
Features
- Multi-protocol digital radio - designed to operate under an NXDN or DMR digital, and FM analogue protocols
- NXDN Conventional and Type-C & Gen2 Trunking
- DMR Tier II, DMR Auto Slot Select & Site Roaming
- Mixed Digital & FM Analogue Operation allows gradual migration at your own pace
- 4-Line Basic Frame (2-Line Main/Sub-LCD, icon & key guide) / 14 Characters
- 5-Line Text Message Frame (3 Lines of Text, icon & key guide)
- 7-color LED indicator
- External and Internal Speaker Switching
- Renowned KENWOOD Audio Quality can be achieved with Active Noise Reduction (ANR) that utilizes built-in DSP
- Software DES and AES Encryptions for NXDN Conventional/Trunking and DMR Conventional protocols
- MIL-STD-810 C/D/E/F/G
Basic Package includes
- D.C. Cable
- Fuse
- Instruction Manual
- Mounting Bracket
- Screw Set
NOTE: The 24 months warranty only applies to the radio, it does not apply to any batteries or accessories shipped within the model package. Service From the Start packages are also available.
Please remember all Companies/Individuals using a Licensed Radio require an Ofcom Licence with which we can assist.
Basic Specifications
Frequency Range | 136 - 174 MHz |
Number of Channels | 512 |
Number of Zones | 128 |
Channel Spacing - Analogue - Wide/Mid/Narrow | 25 kHz/20 kHz/12.5 kHz |
Modulation Limiting - Analogue | ± 5.0 kHz at 25 kHz ± 4.0 kHz at 20 kHz ± 2.5 kHz at 12.5 kHz |
Channel Spacing - Digital - Wide/Narrow | 1.5 kHz/6.25 kHz |
Current Drain | Standby: 0.45 A Receive: 2.3 A Transmit: 9.0 A |
Frequency Stability | ± 1 ppm (-30 °C to + 60 °C) |
Operating Temperature Range | -30 °C to + 60 °C |
Power Supply | 13.2 V DC (10.8 - 15.6 V DC) |
Dimensions | W x H x D: 160 x 43 x 160 mm - Radio with Control Head, projections not included - |
Weight (net) | 1.2 kg - Radio with Control Head - |
For more information and specifications please download the NX3000 Series Product Brochure and the NX-3720E Product Specification
