Motorola R5 Limited Keypad (LKP) Two Way Radio
The Motorola R5 Limited Keypad is a professional MOTOTRBO two way radio designed for users who need loud, clear, reliable communication with the added benefit of a display and keypad for easier navigation and greater control. With advanced noise suppression, intuitive controls, long battery runtime, and a rugged compact design, the R5 helps improve worker efficiency and safety across a wide range of industries.
Built to withstand everyday knocks, drops, dust, and water exposure, the Motorola R5 is rated to IP67 and tested to MIL-STD 810H standards. The limited keypad model also adds a 1.5-inch monochrome display, 256 channels, and expanded zone capacity, making it a strong choice for transport, logistics, manufacturing, construction, facilities, security, and general business use.
| Loud, Clear Audio | Programmable loud audio, AI-trained noise suppression, IMPRES technology, and received audio levelling help keep messages clear in noisy workplaces. |
| Built for Tough Environments | IP67 protection and MIL-STD 810H durability help the R5 withstand dust, water immersion, knocks, and drops. |
| Long Battery Runtime | With the high-capacity 3200 mAh battery, the R5 can deliver up to 32 hours of digital operation under typical conditions. |
| Display & Keypad Control | The limited keypad and monochrome display make it easier to navigate menus, manage channels, access radio functions, and view status information at a glance. |
| Expanded Channel Capacity | With 256 channels and 50 zones, the R5 LKP is better suited to users managing larger radio fleets or more complex channel plans. |
| Compact Professional Design | The R5 combines ruggedness with a sleek compact form factor that is practical for everyday business use. |
| Accessory Flexibility | Compatible remote speaker microphones, earpieces, headsets, and carry accessories help tailor the radio to different roles and environments. |
| Improved Worker Safety | Reliable instant communication helps teams respond faster, coordinate better, and stay connected in higher-risk settings. |
| Future-Ready Platform | As part of the MOTOTRBO range, the R5 supports modern digital radio operation and Motorola’s IMPRES battery and charging ecosystem. |
The Motorola R5 is built to deliver intelligible communication across changing workplace conditions. Motorola states that the R5 combines loud audio, AI-trained noise suppression, IMPRES technology, and received audio levelling to help maintain consistent communications across diverse work settings.
The limited keypad model adds a front-facing display and keypad that make day-to-day operation easier, especially for users working with larger channel plans or more advanced programmed features.
| Display Feature | Benefit to the User |
| 1.5" Monochrome Display | Provides clear visibility of channel, zone, battery, and radio status information. |
| Limited Keypad | Improves menu navigation and access to programmed functions without the complexity of a full keypad radio. |
| Channel & Zone Information | Helps users work more efficiently when managing multiple teams, departments, or operating areas. |
| Battery & Radio Status | Allows quick checks of battery level and active radio settings during the working day. |
The R5 is designed for demanding work environments, with official Motorola documentation listing IP67 protection and MIL-STD 810H ruggedness. Motorola also notes that the radio is dust-tight and waterproof, and has been tested for harsh conditions including drops, vibration, humidity, and temperature changes.
Battery runtime depends on the battery fitted. Motorola’s current R5 datasheet lists up to 21.5 hours digital / 16 hours analogue with the slim IMPRES 2200 mAh battery (PMNN4888), and up to 32 hours digital / 24 hours analogue with the high-capacity IMPRES 3200 mAh battery (PMNN4889), under typical test conditions.
| Model | Part Number | Frequency |
|---|---|---|
| Motorola R5 Limited Keypad - GPS | MDH07JDH9WA1AN | 136–174 MHz VHF |
| Motorola R5 Limited Keypad - GPS | MDH07RDH9WA1AN | 400–527 MHz UHF |
| Motorola R5 Limited Keypad - BT/WIFI | MDH07JDH9SA1AN |
136–174 MHz VHF |
| Motorola R5 Limited Keypad - BT/WIFI | MDH07RDH9SA1AN | 400–527 MHz UHF |
The Motorola R5 Limited Keypad is available in different configurations depending on your operational requirements. The two most common options are the GNSS (GPS) version and the Bluetooth & Wi-Fi version, each designed for different use cases.
| Feature | GNSS (GPS) Version | Bluetooth & Wi-Fi Version |
| Primary Use | Worker safety and location tracking | Connectivity and radio management |
| Location Tracking | Yes – real-time GPS tracking of users | No |
| Emergency Response | Improved response with location visibility | Standard radio communication only |
| Bluetooth Accessories | No | Yes – supports wireless earpieces and accessories |
| Wi-Fi Capability | No | Yes – supports programming and updates over Wi-Fi |
| Remote Programming | No | Yes – update radios without returning to base |
| Best For | Security, lone workers, construction, utilities | Large teams, multi-site operations, facilities |
| System Integration | Works with tracking software (SmartPTT / TRBOnet) | Works with fleet management and update systems |
Important: These features are available on separate configurations. If you require both GPS tracking and Bluetooth/Wi-Fi functionality, please contact us to discuss suitable alternatives.
| Feature | R5 Non-Keypad (NKP) | R5 Limited Keypad (LKP) |
| Best For | Simple push-to-talk users | Users needing more control and flexibility |
| Display | No display | 1.5" monochrome display |
| Keypad | No keypad | Limited keypad for navigation |
| Channel Capacity | 64 Channels | 256 Channels |
| Zone Capacity | Basic | Up to 50 Zones |
| Ease of Use | Very simple operation | More control with menu navigation |
| User Interface | LED indicators only | Display with channel, battery, and status info |
| Audio Performance | Excellent (AI noise suppression) | Excellent (AI noise suppression) |
| Durability | IP67 + MIL-STD 810H | IP67 + MIL-STD 810H |
| Battery Life | Up to 32 hours | Up to 32 hours |
| Connectivity Options | Model dependent | Model dependent (GPS or Bluetooth/Wi-Fi variants available) |
| Typical Use Case | Warehousing, retail, basic operations | Security, logistics, larger teams, multi-channel environments |
| Frequency Range: | VHF 136–174 MHz / UHF 400–527 MHz |
| Power Output: | VHF up to 5W / UHF up to 4W |
| Channel Capacity: | 256 Channels |
| Zone Capacity: | 50 Zones |
| Display: | 1.5" monochrome display (132 x 48 px) |
| Power Supply: | 7.5 V nominal |
| Battery Option 1: | IMPRES Slim Li-Ion IP67 2200 mAh (PMNN4888) |
| Battery Option 2: | IMPRES High Capacity Li-Ion IP67 3200 mAh (PMNN4889) |
| Dimensions with PMNN4888: | 122 x 56 x 35 mm |
| Weight with PMNN4888: | VHF 285 g / UHF 269 g |
| Dimensions with PMNN4889: | 122 x 56 x 41 mm |
| Weight with PMNN4889: | VHF 318 g / UHF 301 g |
| Operating Temperature: | -20°C to 60°C |
Browse compatible Motorola R5 accessories, including batteries, chargers, earpieces, and remote speaker microphones.
| Product | Part Number |
|---|---|
| IMPRES Li-Ion IP67 2200 mAh Battery | PMNN4888 |
| IMPRES Li-Ion IP67 3200 mAh Battery | PMNN4889 |
| Product | Part Number |
|---|---|
| Motorola Single Unit Charger, IMPRES, UK Plug | PMPN4572A |
| Motorola IMPRES 6-Way Multi-Unit Charger UK | PMPN4290 |
| Product | Part Number |
|---|---|
| 2-Wire Surveillance Earpiece Kit - Black | PMLN7269 |
| IMPRES Remote Speaker Mic IP55 | PMMN4073A |
| Remote Speaker Mic IP57 with Enhanced Noise Reduction | PMMN4075A |
The Motorola R5 is a licensed two way radio. Use in the UK normally requires an Ofcom radio licence. We can assist with licence applications and setup if required.
The Motorola R5 Limited Keypad is designed for professional users who need loud, reliable push-to-talk communication with the added benefit of a display and keypad for easier channel management and menu navigation.
The Motorola R5 supports both analogue and digital operation.
The Motorola R5 limited keypad model has a channel capacity of 256 channels, making it better suited to larger or more complex radio fleets than the non-keypad version.
Yes. The limited keypad version includes a 1.5-inch monochrome display that shows radio status, channel, zone, and other key operational information.
Yes. The Motorola R5 is rated IP67, meaning it is dust-tight and protected against temporary immersion in water under the rated conditions.
Yes. Motorola states that the R5 is rugged to MIL-STD 810H and designed to withstand drops, vibration, humidity, and temperature changes found in harsh working environments.
Battery life depends on the battery fitted. With the PMNN4888 2200 mAh battery, Motorola lists up to 21.5 hours digital runtime, while the PMNN4889 3200 mAh battery can provide up to 32 hours digital runtime under typical test conditions.
The Motorola R5 Limited Keypad is available in VHF 136–174 MHz and UHF 400–527 MHz variants.
Motorola provides a wide R5 accessory ecosystem including original batteries, remote speaker microphones, earpieces, headsets, and charging solutions.
Some R5 LKP configurations are available with Bluetooth and Wi-Fi, but these features are not included on every limited keypad model as standard. It is best to confirm the exact specification of the part number being supplied.
For many users, yes. The R5 combines modern MOTOTRBO digital operation, long battery runtime, improved audio processing, and rugged construction, making it a strong upgrade option for businesses replacing older professional handheld radios.
The Motorola R5 Limited Keypad is a strong choice for businesses that need a tough, easy-to-use digital two way radio with loud audio, long runtime, dependable day-to-day performance, and added display and keypad functionality for more efficient operation.
| Feature | Motorola R2 | Motorola R5 | Motorola R7 |
|---|---|---|---|
| Best For | Everyday business use | Noisy environments & industrial use | Advanced features & large operations |
| Audio Quality | Good | Excellent (AI noise suppression) | Premium (dual mic noise cancellation) |
| Durability | IP55 | IP67 + MIL-STD 810H | IP68 + MIL-STD 810 |
| Battery Life | Standard shift | Up to 32 hours | Up to ~28 hours (model dependent) |
| Channels | 64 | 256 (LKP) / 64 (NKP) | 64 (NKP) / Higher on keypad models |
| Display Options | Non-display | Limited keypad with monochrome display | Full keypad & display options available |
| Noise Suppression | Basic digital | AI-trained noise suppression | Advanced dual microphone suppression |
| Connectivity | Basic | Model dependent | Bluetooth, Wi-Fi, GNSS (Premium models) |
| Security | Basic & Enhanced Privacy (licence required) | Basic & Enhanced Privacy | Enhanced + AES256 (licence required) |
| Typical Users | Retail, small teams | Construction, logistics, manufacturing | Security, airports, large operations |
