Text messaging and Work Order Ticketing simplify complex communications, and data capabilities support advanced applications. Featuring a high power audio amplifier, these radios deliver loud, clear speech, with background noise cancellation for better intelligibility. DM4000e Series radios are also ideal as a dispatcher solution, with desktop microphones and a rugged, durable design for everyday use.
If you are interested in the Bluetooth, Wi-Fi or location tracking features, please see the DM4401e Radio.
Features
- UHF1 (403-470MHz) LP/HP; VHF (136-174MHz) LP/HP; UHF2 (450-527MHz) LP-HP
- Channel Spacing 12.5/20/25kHz (UHF/VHF); 12.5/25kHz (UHF2)
- IP54 rated
- 99 channels
- 2-digit numerical display
- 3 watt built-in loudspeaker for clear audio
- Rugged front & rear accessory connectors
- Accessory connector supports USB interface
- 4 programmable buttons to improve ease-of-use and increase operator efficiency
- Multi-coloured LED indicators provide clear feedback on radio operating status
- Quick, easy-to-use Group, Individual and All-call capability
- PTT ID helps improve communications efficiency and system discipline
- Remote Monitor features
- Intelligent Audio feature automatically adjusts the radio volume according to the environment's noise level
- Voice announcement of channel change and feature activation
- 5 Tone analogue feature support
- Basic / Enhanced Privacy
- AES256 Encryption via Software Purchase
- VOX Capability
- Lone Worker
- Direct Mode (including Dual Capacity Direct Mode)
- IP Site Connect (Single and Multi-Site)
- Capacity Plus (Single and Multi-Site)
- Capacity Max via Software Purchase
- Connect Plus via Hardware and Software Purchase )
- Memory (128MB RAM & 256MB Flash memory
Basic Package includes
- Compact Microphone (RMN5052_)
- Low Profile Trunnion (RLN6466_)
- Power Cable (HKN4191_)
- In-box Documentation (QRG option, Safety, RTTE Leaflet)
Basic Specifications
Frequency Range | VHF 136 - 174 MHz UHF 403 - 470 Mhz |
Power Output |
VHF High Power: 25-45W VHF Low Power: 1-25W UHF High Power: 25-40W UHF Low Power: 1-25W |
Channel Capacity | 99 |
Antenna Impedence | 50 Ω |
Dimensions (HxWxD) | 53 x 175 x 206 mm |
Weight | 1.8kg |
For more specifications please download the product brochure
