Kenwood Programming Software KPG-D7 - NXR-1700/NXR1800 Radios

by Kenwood
Original price £99.99 - Original price £99.99
Original price
£99.99
£99.99 - £99.99
Current price £99.99
+ VAT
Walkie Talkies

Kenwood KPG-D7 Programming Software

This is the software required to program the Kenwood 1000 series repeater radios including the NXR1700 and NXR1800 Radios.

This software comes in two parts:

  • Part 1: Software downloadable after purchase
  • Part 2: Seperate licence key direct from Kenwood to activate (usually issued via email within 24 hours) Every licence key is registered to the end user and without it you cannot use the software.
  • Both parts are included in the price

Version 200 - File Size 56MB

Software Code: KPG-D7

Please note No Refunds are offered on this product as it is downloadable at point of sale.

***This product is excluded from our Money  Back Guarantee***

This software is designed to be used on the following radios:

  • Kenwood NXR-1700 Radio.
  • Kenwood NXR-1800 Radio.

    Installation of Kenwood Customer Programming Software

    • Download via the link provided when purchased
    • Unzip file and click install
    • Follow the onscreen installation steps
    • The software may require a few additional windows programs to update before installation, no additional cost just follow instructions and your computer may restart several times.
    • Once installed we suggest restarting your computer normally gets rid of any glitches you may experience or issues connecting radios.
    • We suggest shutting down other programs like Outlook etc as it can slow your computer down.
    • Open your Kenwood License Management Client (See Video Below)
    • Enter the Unique Licence Key we send you from Kenwood
    • Once activated open KPG-D7 software - Programs - Kenwood FPU - KPG-D7
    • Connect radio using the Programming Lead or you can do it through IP configuration - See below Programming Through IP
    • Power on the radio
    • Select Read on the top tab
    • It will read the radio and show you the current codeplug in the radio
    • Go through the options and program as necessary
    • Once you have created your code plug, Save and name it clearly so you can find it in the future.
    • Now press Write - to send the information back into the radio
    • The radio will power down and back up once it has been programmed and notify you on the screen.
    • If you wish to connect another radio - connect and then select 'Write'

    Kenwood Licence Key Activation/Deactivation Video

    Your Licence key is created by kenwood and we will forward it on as soon a we receive it. The process normally takes 24 hours. Please see below video of how to activate your Kenwood Radio Licence software. Also a link to the latest License Management Client.

    https://www.kenwood.com/content/dam/kenwood/jp/support/com/kpt-300lmc/KPT-300LMC_V200.zip

    Programming Through IP address

    Connect the repeater to your network using a Network cable and connect your computer as well using a network cable, Power on the repeater then change the IP setting of your computer to the following:

    Windows 11 - Network and Internet Settings - Ethernet - IP Assignment - Edit

    IP Address: 192.168.0.2

    Subnet Mask: 255.255.255.0

    Default Gateway: 192.168.0.1 or you can use 192.168.0.254

    The repeater has a factory setting of 192.168.0.1 so to access it you need to be on the same IP range and subnet mask.

    Then type 192.168.0.1 into your internet browser and you will now see the GUI inteface for the repeater.

    Tips for programming

    • Read your radios before and after and you dont have to rewrite the codeplug from scratch in the CPS if you make a error.
    • Always keep a copy of the original blank code plug, when it comes to selling the radio later you can load it back to factory settings easily.
    • Each radio model has its own code plug so you can only Clone a TK2108 using a TK2108 code plug.
    • Read = Reads the Radio
    • Write = Sends the code plug to another radio which is the same model

    Disclaimer:

    Administration fee - Please note you are paying for access to the storage of the software on our online portal and not the software itself. As you can imagine it cost to host large files online which are easily accessible to our customers. The price is normally in reflection to the size of the downloadable file and the storage it takes up. Once Payment has been received and processed through our fraud detection system you will receive a link which will enable you to download the software from our portal. All software rights remain that of the manufacturer and you will not own this software at any point. You are free to use the software for its necessary purpose, but any misuse could make you liable by the software manufacturer.

    We do not offer any support or refunds on software purchases please read all the information above carefully before you purchase. If you are in any doubt we can create a codeplug for you please just get in touch via email sales@radio-shop.uk and subject title CODEPLUG and we can discuss the price for this service. Please remember to include the make, model and channel requirements.
